Quick Details

  • Place of Origin: Jiangsu, China (Mainland)
  • Brand Name: PASSPOWER
  • Model Number: P5000W
  • Output Power: 5000W
  • Output Type: Single
  • Size: 545*199*146(mm)
  • Weight: 12.3kg
  • Input Voltage: 12V / 24V / 48V
  • Output Voltage: 110V/220V/230V/240V
  • Type: DC/AC Inverters
  • Output Frequency: 50Hz or 60Hz
  • Output Current: 20.8A~50A
  • Output Waveform: pure sine wave
  • Efficiency: >86%~90%
  • Item: inverter for home use
  • Start Way:: soft start
  • Grid Type: off-grid
  • THD: <3%
  • Warranty Year: one year
  • Certification: CE,ROHS,GMC,SGS,IP30
  • Application: home appliance, office, car,boat, solar system
  • Market: all the world

Packaging & Delivery

Packaging Details: carton with foam inside for inverter for home use caravan/motorhome/ice cream machine home inverter 48v
Delivery Detail: Shipped in 2 days after payment

inverter for home use caravan/motorhome/ice cream machine home inverter 48v

Product Description



Features

inverter for home use caravan/motorhome/ice cream machine home inverter 48v

1.High transform efficiency &fast start

2.Pure sine wave output waveform

3.Soft start function

4.Strong adaptability and stability

5.With automatic over-current and output short circuit protection to avoid damage the equipment

6.Temperature controlled fan, safe & efficient

7.Safe and reliable with built in fuse

Notice: Customizable input voltage such as 36V,72V,96V,110V etc; output voltage such as 120v, 200v

Technical Data

inverter for home use caravan/motorhome/ice cream machine home inverter 48v




ModelP5000-12-110P5000-24-110P5000-48-110P5000-12-220P5000-24-220P5000-48-220
Power5000W5000W5000W5000W5000W5000W
Peak Power 10000W(within 5 millisecond)
DC Input Voltage 12V24V48V12V24V48V
AC Output Voltage 110VAC±10%220VAC±5%
No-load Current <2.5A(DC13V)<1.7A(DC26V)<1.5A(DC52)<2.5A(DC13V)<1.7A(DC26V)<1.5A(DC52)
AC Output Frequency 50HZ±1%/60HZ±1%
Output waveformpure sine wave
Wave DistortionTHD<3%
Full Load Efficiency >86%(DC13V)>88%(DC26V)>90%(DC52V)>86%(DC13V)>88%(DC26V)>90%(DC52V)
DC Input Voltage Range 11V~15.5V22V~31V44V~62V11V~15.5V22V~31V44V~62V
Lower Voltage Alarm11±0.3V22±0.5V44±1V11±0.3V22±0.5V44±1V
Lower Voltage Shutoff 10.5±0.3V21±0.3V42±0.5V10.5±0.3V21±0.3V42±0.5V
Higher Voltage Shutoff 15.5±0.3V31±0.5V62±0.5V15.5±0.3V31±0.5V62±0.5V
Lower Voltage Recovery 12.4±0.1V24.8±0.2V49.6±0.3V12.4±0.1V24.8±0.2V49.6±0.3V
Higher Voltage Recovery15.4±0.1V30.8±0.2V61.8±0.5V15.4±0.2V30.8±0.4V61.8±0.5V
Over-load Shutoff112%~114%
Protect Function Lower voltage:Red LED light on; the buzzer alarms; the inverter recovers to be normal automatically
Higher Voltage:Red LED light on;the inverter recovers to be normal automatically
Over-load:Red LED light on;the inverter recovers to be normal automatically
Over-Temperature:Red LED light on; the buzzer alarms; the inverter recovers to be normal automatically
Short-Circuit(within 2 seconds):the inverter recovers to be normal automatically
The anode and the cathode are connected in the wrong way: the fuse blowouts
Operating Temperature–10℃- +50℃
Storage Temperature–30- +70℃
Humidity20%~90%RH without condensation
Operating Altitude less than 1200m
Net Size 545*199*146mm
 Net Weight 12.46±0.03kg12.45±0.02kg12.26±0.02kg12.46±0.03kg12.1±0.02kg12±0.02kg
Packaging Size 665*285*240mm(1pc)
Gross Weight 15.25±0.1kg14.58±0.1kg14.22±0.1kg15.4±0.1kg14.52±0.1kg14±0.1kg




  Detailed Picture

inverter for home use caravan/motorhome/ice cream machine home inverter 48v





Application

inverter for home use caravan/motorhome/ice cream machine home inverter 48v

Used in Car,Yacht,Solar energy systems,Mobile devices,Industrial controls,Power tools,Home office and so on solar inverter solar inverter solar inverter



 inverter for home use,inverter for home use, inverter for home use, inverter 5000w
Packaging & Shipping

   Package & Delivery

Shipping Terms:solar inverter solar inverter solar inverter

1) International Express: FedEx/DHL/UPS/TNT/EMS etc.solar inverter solar inverter solar inverter

2) FOB Shanghai, Ningbo or Shenzhen Sea Port China.solar inverter solar inverter solar inverter

    EXW/CIF/CFRsolar inverter solar inverter solar inverter

    Delivery goods with 7-30 days after receive the deposit for bulk order, sample order:2-3 dayssolar inverter solar inverter solar inverterinvertor invertor invertor


Company Information

   Company Profile

Su Zhou Maili Electrical Appliance Co. LTD is a professional manufacture and exporter in the field of inverter,

battery charger power supply for more than 10 years. It is integrated the inverter production, R&D,and sales team

together.It is located in the National advanced technology development zone of Yangtze river delta. It has developed

into the modern science and technology enterprise, owing to the convenient location, strong industrial foundation, the

advantageous talents teams. inverter for home use,inverter for home use, inverter for home use, inverter 5000w



Pass Power Products Range







Our Services

 Pass Power Service

1. Samples

Samples are Available for Testing and Market Test.

2. Warranty of  Pass power Productsinverter for home use,inverter for home use, inverter for home use, inverter 5000w

PASS POWER provides one year warranty inverter for home use,inverter for home use, inverter for home use, inverter 5000w

3. Guides and After-service Consultancy

PASS POWER Team will offer these guides below.inverter for home use,inverter for home use, inverter for home use, inverter 5000w

  A. Need an Accessory?             B. Products Repair?

  C. Power Problems to Solve?    D. Power Protection Solutions, etc.?

4. OEM Service

 Certificates

Our Company achieves  CE, RoHs certifications.

 Exhibitions

Welcome to contact us

If you want to know more about inverter for home use caravan/motorhome/ice cream machine home inverter 48v,

please feel free to contact me. My skype is inverternian, wechat/whatsapp is 0086 13625278977 inverter for home use,inverter for home use, inverter for home use, inverter 5000w
